Signal Line Common Mode Chokes/Filters

Chip Beads

MMZ1608B102CTD25

|Z|=1000Ω at 100MHz
Rated current=300mA

L x W x T :
1.6mm x 0.8mm x 0.8mm

3-terminal Filters

YFF15SC1H220MT000N

Insertion Loss=30dB (4000MHz to 6000MHz)
Cut-off Freq.=300MHz
Rated current=2A

LxWxT: 1x0.55x0.3mm
For Signal Line

Signal Line Common Mode Chokes/Filters

ACM2012H-900-2P-T03

|Z|=90Ω at 100MHz
Rated current=300mA

L x W x T :
2mm x 1.2mm x 1.2mm

Signal Line Common Mode Chokes/Filters

ACT1210E-241-2P-TL00

L=240μH
Rated current=70mA

L x W x T :
3.2mm x 2.5mm x 2.5mm

Signal Line Common Mode Chokes/Filters

ALC2012-900-2P-T00

|Z|=90Ω at 100MHz
Rated current=400mA

L x W x T :
2mm x 1.2mm x 1.2mm

Signal Line Common Mode Chokes/Filters

ALC2012H-900-2P-T10G

|Z|=90Ω at 100MHz
Rated current=300mA

L x W x T :
2mm x 1.2mm x 1.2mm

Signal Line Common Mode Chokes/Filters

B82720H0015A025

|Z|=5200Ω at 0.1MHz
Rated current=0.6A

L x W x T :
13.0mm x 9.5mm x 14.3mm

Signal Line Common Mode Chokes/Filters

B82720S0182A020

L=0.88mH
Rated current=1.8A at +40°C

L x W x T :
12.7mm x 12.7mm x 5.46mm

Signal Line Common Mode Chokes/Filters

B82790C0105N240

Rated current=0.5A

L x W x T :
9.0mm x 6.0mm x 5.2mm

Signal Line Common Mode Chokes/Filters

MCZ1210DH500CPTA0G

|Z|=45Ω at 100MHz
Rated current=0.1A

L x W x T :
1.25mm x 1mm x 0.5mm
