Magnetic Current Sensors

MLCC with Dipped Radial Lead

FA22C0G2W683JNU06

Capacitance=68nF
Edc=450V
T.C.=C0G

LxWxT:7.5x8.5x4.5mm, Lead pitch:5mm
AEC-Q200
General

Ultra High Voltage Ceramic Capacitors

FD-11AT

Capacitance=500pF
Edc=10kVac
T.C.=Y5P

φDxL: 28x27mm
For Distribution Lines

SMD / SMT Inductors (Coils)

BCL3520FT-R47M-D

L=0.47μH
Rated current=8.0A

L x W x T :
3.3 x 3.5 x 2.0mm

Ring Varistors

VAR-18230550Y7P

O.D / I.D = 23mm / 15mm

E10= 40 to 70V

NTC Elements

NTCWS3JF103HC1GTxxx

Nominal Resistance=10.00kΩ at 25℃

Nominal Resistance Tolerance=±3%

NTC Elements

NTCWS3UF103HC1GT90A

Nominal Resistance=10.00kΩ at 25℃

Nominal Resistance Tolerance=±3%

Magnetic Current Sensors

HAL2420UT

Analog Output

Redundancy=No
Integrated Capacitors=No

Magnetic Current Sensors

HAR2455

PWM Output

Redundancy=YES
Integrated Capacitors=No

Magnetic Current Sensors

TCM1110-BABA

Analog, SENT

Redundancy=No
Integrated Capacitors=No

Direct Angle Sensors

HAC3930CX

PWM/SENT/Switch Output
TO92UF

Redundancy=No
0 (Single)
Integrated Capacitors=Yes
Angle Accuracy (Over All Temperature)=+/- 0.6 deg
