Rx Coil Units

Baluns

ATB2012-75011M-T000

Pass Band=400 to 1800MHz

Bal. Port Zc=75Ohm

Magnetic Toner Density / Quantity Sensors

TS0505ANK-XXX

Sensor Dia.(Nom)=8mm

Output Signal=Analog

Magnetic Toner Density / Quantity Sensors

TS0524ANK-XXX

Sensor Dia.(Nom)=8mm

Output Signal=Analog

µPOL™ Embedded DC-DC Converters

FS1003-0600-SK

L x W x T :
3.3 x 3.3 x 1.35mm

Vin: 4.5 to 16V
Vout=0.6V, Iout=3A

µPOL™ Embedded DC-DC Converters

FS1006-3300-SK

L x W x T :
3.3 x 3.3 x 1.35mm

Vin: 4.75 to 16V
Vout=3.3V, Iout=6A

NFC Antenna Combo Rx Coil Units

WR524825-17M6-NF-G

Dimensions = 52.0mm x 48.0mm

Inductance=16.8μH to 100kHz

Tx Coil Units

WT505090-10F2-LP-G1

Dimension = Φ51.4mm

Inductance=6.3μH at 100kHz

Rx Coil Units

WR121210-27M8-ID

Dimensions = Φ12.0mm

Inductance=8.32μH at 100kHz

Rx Coil Units

WR202010-18M8-ID

Dimensions = Φ20.0mm

Inductance=11.0μH at 100kHz

Rx Coil Units

WR221230-36M8-G

Dimensions = 22.0mm x 12.0mm

Inductance=27.9μH at 100kHz
